2023 CORTES CAMPER 17

EXTERIOR DIMENSIONS
Trailer Length:18 ft 1 in
Width:                6 ft 9 in
Height:               6 ft 9 in
Height (A/C)      8 ft 9 in

INTERIOR
LED Lighting
• Bathroom, Under Cabinet Lighting
Air Conditioner
• 14,500 BTU
Propane Furnace
• 19,000 BTU
On-Demand Tankless Water Heater
• 14,300 Max BTU
Water Pump
• 12-Volt 3 GPM Max Flow
Battery Monitoring System
35A Power Center
• Outlets - 120-Volt
Double Pane Acrylic Windows
• Screens and Blinds (Built-in) with Multi-
Function Opening

DINING AND SLEEPING
Dining Tables
•Table Seating Area for 4
•Side Table Seating Area for 1
•Telescopic, Multi-Function Pedestal Mount
for Dinette Table/Bed
STORAGE
• Marine Hatch Storage Compartments
LEISURE CENTER
• HD LED TV 19-inch Color
• Bluetooth Radio/2 Speaker System

KITCHEN
Ductless Hood Vent
• 12-Volt RV Ductless Range Hood with
Charcoal Filter
Oven and Range
• 17-inch RV Gas Oven Range with 3-Burner
Cooktop
Microwave
• Over-the-Range .9 cubic ft Microwave Oven
Refrigerator
• 8.0 cubic ft 12-Volt Built-in Refrigerator
Workstation Sink
• Kitchen Sink (16-Gauge Stainless Steel)
• Cutting Board (Removable)
• Goose Neck Faucet

BATHROOM
Stainless Steel Bathroom Sink
• Faucets (Brushed Nickel)
Porcelain Toilet
• Low Profile Gravity Flush Toilet
Shower with Handheld Multi-Setting Shower
Head (Brushed Nickel)
• High Pressure / Low Pressure Water Supply

HOLDING TANKS
• Fresh Water 42 Gallon
• Grey Water 26 Gallon
• Black Water 16 Gallon
• Heated tanks

EXTERIOR
LED Porch Light
Exterior Door with Screen and Key Lock
Stainless Steel Grab Handle
Step Up to Door – Steel Fold Up
Propane 20 Pound Tanks (2)
Propane Port Hook Up
Propane Gas Gauge and Leak Detector
Hook Ups
• Fresh Water Fill
• City Water Direct
30A Power Shore Inlet
Shore Power Hook Up
Dual Battery Storage Box
• Battery (2) – 12-Volt Batteries (Dealer
Supplied)
GFCI Protected 110 Volt Outlet with Cover
